OMPHOBBY 67”/104" Extra NG Airplane
OMPHobby 67”Extra NG is a lightweight and easy-to-fly model that delivers excellent performance with its sleek design and powerful performance it's sure to take your flying experience to new heights.
It's a fantastically balanced aircraft, precise yet aggressive, and for pilots who prefer a natural look , it flies great even without SFG wing tips, it is also highly visible even when the sun is low, largely thanks to the graphic design, which, same as on the full scale Extra NG, comes from Italy.
And the Extra is super stable in during high speed maneuvers as well as low and slow flying. The construction is heavily reinforced with carbon fiber so it's able to withstand a lot.
Parameter Specification
WingSpan:1700mm(67in)
Full Length:1715mm(67.5in)
Flight Weight: 3.8KG
Wing Area:57.58d㎡
Wing Load:15.99g/d㎡
Wing Angle of Incidence:0°
Motor Thrust Angles:Down 0° & Right 3°
Pack Dimension: 158*51*30(L*H*W)cm
Gross Weight: 8.34KG
The Center of Gravity (CG):
Approx.130mm (measured from wing leading edge at root)
Electric Power (Recommended):
Motor: Sunnysky X6215 420KV 25cc
ESC: Sunnysky X125A PRO
Propeller: Eolo 18*10”
Lipos: 6S 4200mAh-4500mAh
Servo: 20 Kg.cm*4 (Aileron*2,Elevator*1, Rudder*1)
Servo Arm: 1.25" 25T Servo Arm
Recommended Settings of Dual Rates and Exponentials of Control Surfaces:
